Model year : 2017
Range of hammering energy：0.5～25J（0.37～18.4ft-lbs）NOTE:with an extra plate or table, 50J（36.8ft-lbs）
Release of hummer and brake : manual
Regulations of test : for Charpy, ISO179, ASTM D6110, DIN53453, DIN53753, BS7413 etc.
for Izod, SO180, ASTM D256, ASTM D4812 etc.
for tensile strength and shock test, ISO8256 typea A and B etc.
for pipe, ISO9854、ISO7628
for die in stat, DIN53435、DIN51230
for breaking strength, ISO17281
NOTE: the constitution is in Chapy 50J hummer type.
Angle measurement : measured by non-contact digital and magnetic encoder, 7200divisions and 0.05° as resolution
Internal transducer : strain gauge/piezoelectric element, ±１％（more than１０%FS）as accuracy
System requirements : 15~35℃ as room temperature 85％ as room humidity without dewing
Noise : Lower than Lw70dB
External dimension and weight：W1035×D430×H895mm, approx. 220kg
Power supply : AC100～120/220～240V 50/60Hz
Protective cover : CE regulated
Attached hummer：Certificate code 0080.054（Charpy 50J）
