Keysight Technologies (Agilent HP) 435A () Main Features and Specifications

Product Specs

  • Status Discontinued
  • Alternative No replacement

The 435A power meter and a compatible power sensor are interconnected with the power sensor cable to form a power measurement system. The system power level range, frequency response, and load impedance are dependent on the power sensor.

  • Internal automatic zeroing circuit removes error due to the ambient temperature output of the power sensor
  • A calibration factor adjustment accounts for error due to frequency response of the power sensing device
  • Internal calibration reference
  • Power range:
    • Watts: Full-scale ranges of 3, 10, 30, 100, 300 uW; 1, 3, 10, 30, 100 mW
    • dB: -25 dBm to +20 dBm
  • Noise and drift: 1.5% of full-scale peak on 3 uW range, less on higher ranges (typical)
  • Calibration factor: 16-position switch normalizes meter reading to account for calibration factor or effective efficiency. Range is 100% to 85% in 1% steps
  • Recorder output is proportional to indicated power with 1 volt corresponding to full scale
  • RF blanking output: Provides a contact closure to ground when auto-zero mode is engaged
  • Options: Rechargeable battery, rear panel connector in parallel with front panel input connector, rear panel connector to replace the standard front panel connector, cable options
